AI-generated FDM process illustration; not a photograph of FDM 220, the quoted equipment or a delivered unit. Enclosure, head count and auxiliaries shown do not establish this model's configuration.

FDM · Model reference

EverBen FDM 220 3D Printer: specifications and configuration review

FDM 220: 220 × 220 × 250 mm FDM reference with a 330 °C nozzle and 120 °C bed entry. Constant-temperature chamber wording lacks a setpoint or control specification.

Request this configuration Compare adjacent models ↓

AI-generated FDM process illustration; not a photograph of FDM 220, the quoted equipment or a delivered unit. Enclosure, head count and auxiliaries shown do not establish this model's configuration.

Processfilament extrusion / FDM

Current availabilityPending confirmation

Specification statusNeeds configuration confirmation

Reference reviewed2026-09-08

Configuration decisions

What to resolve for FDM 220

What does the chamber description actually provide?

The source describes a fully enclosed constant-temperature chamber with a dual-swing door; the spelling is corrected. It does not state chamber temperature, active heating, sensor locations or temperature uniformity.

What is missing behind the 600 mm/s ceiling?

Decision coverage

Selection fields and gaps

Values below come from this model’s reference table. A pending field must be resolved before it is used for selection; a material-family list does not qualify a grade.

Build envelope: 220×220×250mm
Layer setting: ≥0.05mm
Nozzle diameter options: 0.4mm
Material grade / qualification: Not supplied in this reference record — request a configuration-specific value.
Nozzle temperature: Max 330°C
Chamber heating / enclosure: Fully Enclosed Constant-Temperature Chamber (Dual-swing Door Design)
Electrical supply: AC100V-AC240V 50Hz/60Hz
Rated load (reference; scope to confirm): Not supplied in this reference record — request a configuration-specific value.

Adjacent configurations

Compare FDM 220 with FDM 160 and FDM 334

Each pair uses the same decision fields. These are source-record differences; output, compatibility and current supply require confirmation for both configurations.

FDM 220 / FDM 160

Reference comparison; unconfirmed fields remain open
Field	FDM 220	FDM 160
Build envelope	220×220×250mm	160×160×190mm
Nozzle diameter options	0.4mm	0.2/0.3/0.4/0.6mm
Nozzle temperature	Max 330°C	Max 260°C
Chamber heating / enclosure	Fully Enclosed Constant-Temperature Chamber (Dual-swing Door Design)	Not fully enclosed
Machine outline (auxiliaries may be excluded)	402×420×543mm	317×366×398mm
Machine mass (check net/gross basis)	≥25kg	≥12kg

FDM 160: 160 × 160 × 190 mm FDM reference explicitly listed as not fully enclosed, with one nozzle. Its AC100–240 V / 50–60 Hz supply is now included in coverage.

Review FDM 160 specifications →

FDM 220 / FDM 334

Reference comparison; unconfirmed fields remain open
Field	FDM 220	FDM 334
Build envelope	220×220×250mm	300×300×400mm
Nozzle diameter options	0.4mm	0.4mm
Nozzle temperature	Max 330°C	Max 330°C
Chamber heating / enclosure	Fully Enclosed Constant-Temperature Chamber (Dual-swing Door Design)	Pending confirmation — see this model’s reference issues
Machine outline (auxiliaries may be excluded)	402×420×543mm	460×460×760mm
Machine mass (check net/gross basis)	≥25kg	≥50kg

FDM 334: 300 × 300 × 400 mm filament reference with conflicting enclosure and speed descriptions. Treat structure and operating speed as pending when comparing with FDM 3040.

Review FDM 334 specifications →

Reviewed reference record

Basic Parameters for EverBen FDM 220 3D Printer

Reviewed on 2026-09-08. This is a third-party source record for an EverBen inquiry designation. It does not establish a current signed specification, model mapping or supply authorization.

Build Size: 220×220×250mm
Machine Size: 402×420×543mm
Printing Technology: Fused Deposition Modeling (FDM)
Layer Resolution: ≥0.05mm
Air Filtration System: Yes
Filament Run-out Alarm: Yes
Camera: Yes
Leveling Method: Automatic Leveling
Number of Nozzle(s): 1
Printing Speed: ≤600mm/s
Movement: Corexy
Motor Drive: TMC2209
Machine Structure: Fully Enclosed Constant-Temperature Chamber (Dual-swing Door Design)
Filament Storage Box: Externally Mounted Hanging Type
Lighting Function: Built-in LED Lighting
Default Nozzle Diameter: 0.4mm
Nozzle(s) Temperature: Max 330°C
Heated Bed: Max 120°C
Display: 4.5-inch Touchscreen
Connectivity: USB Drive, LAN (WiFi)
Power Requirements: AC100V-AC240V 50Hz/60Hz
Operating System: Windows, Linux, MAC
File Format: STL, GCODE, OBJ
Recommended Operating Temperature: 15°C-32°C
Storage Temperature: 0°C-32°C
Gross Weight: ≥25kg

Needs configuration confirmation

The source gives a single 0.4 mm default nozzle, ≤600 mm/s, filtration and a gross-mass lower bound of 25 kg. Filament grade, sustained melt flow, electrical load and filtration test performance are not supplied. Current availability, EverBen-to-source model mapping and signed specification revision require confirmation.

Source and corrections

Reference status and open fields

Legacy source record — Model parameter table and overview; reviewed 2026-09-08. Source revision not stated; request a current controlled datasheet and model mapping.

The legacy record does not establish a current manufacturer, supply authorization or EverBen model mapping. Request the current controlled datasheet with your inquiry.

AI-generated FDM sample illustration; not a measured sample from FDM 220. Material, finish and performance require the benchmark below.

Model-specific acceptance

Benchmark to request for FDM 220

Record temperature stability and measured dimensions on the 220 mm footprint, testing speed only with a named filament, layer and demonstrated flow rate.

The report should name the machine revision, material lot, parameters, post-processing and measurement method, with raw results and agreed acceptance limits.

Request this benchmark

Further planning

Process, installation and purchasing guidance

filament extrusion / FDM process and material guide · Installation, training and acceptance scope · MOQ, quotation and commercial questions

Request a signed model/configuration mapping, current datasheet, genuine model photographs and a quotation naming the supply and warranty parties.

Next practical step

Resolve the FDM 220 configuration.

Send the part envelope, material grade, quantity and destination with the open fields above. Request the matching specification and acceptance plan with your quotation.

Request a model quotation
